HRG14H

Size ：29.0×12.6×20.6(mm)

Max.16A switching capability

Creepage distance:8mm

Direlectric strength 5000V

Odering Information
							① Part No.
HRG14H	S	DC12	C	X			② Enclosure :Plastic sealed
①	②	③	④	⑤			③ Coil Voltage :
							DC 5 ,6, 9,12, 24V,48V
							④ Contact form:
							A: 1N/O C: 1C/O
							⑤ Special requirment
Specification:
Contact					Characteristics
Contact Form		1 Form C ,1 Form A			Insulation resistance		Min 1000MΩ(500VDC)
Contact Material		Ag Alloy			Dielectric Strength	Between contact 1000VAC 1min
Contact Resistance		100 mΩ(6VDC 1A)				Between coil &contact 5000VAC 1min
Contact Rating(Resistance Load)					Operate time		≤ 15ms
Resistive : 16A 250VAC/30VDC					Release time		≤ 8ms
					Shock Resistance	Endurance	100 m/s2
						Damage	1000 m/s2
Max Switching Voltage		277VAC/30VDC			Vibration Resistance		10-55 HZ 1.5mm DA
Max Switching Current		16 A			Humidity		35%-95% RH
Max Switching Power		4000VA 480W			Ambient Temperature		-35 ℃ to 70℃
Electrical Life		100,000 ops			Weigt		Approx. 13.0g
Mechanical Life		1,000,000 ops			Noted :the data are initial value
Coil Data:					at 23℃
			(540mW)
Nominal Voltage VDC		Operate Voltage Max VDC		Release Voltage Min VDC			Max Voltage VDC	Coil Resistance Ω +/- 10%

5		3.75		0.50			7.00	47
6		4.50		0.60			8.50	68
9		6.75		0.90			12.50	160
12		9.00		1.20			16.80	275
24		18.00		2.40			33.50	1100
48		36.00		4.80			67.20	4170

Dimension(mm)
